Page 3–52 Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
Chapter 3: Configuration and Parameters
parameTer deTails – “i/o” menu of parameTers (ConTinued)
P13.2 – Analog Output: Scaling Level Type:
Description:
Read/Write
Allows the selected function to be scaled. The output will change in proportion with the selected
function.
• The output will be at a maximum when the selected function equals the “Scaling Level.”
Range: Modbus Decimal Value: Default:
0 – 16384 linear scale ( 1 = 0.006104 % )
0% – 100% = (0 – 16384)
x% / 0.006104% = Modbus dec. value
EX: Modbus value of 5250 = 32.05%
0
Modbus Address: Modbus Format:
9088 ( 2380 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Analog Outputs → Scaling Level
i/o “pTC moTor ThermisTor Trip” parameTer
P14.0 – PTC Motor Thermistor Trip Hold. Reg. Type:
Description:
Read/Write
A single PTC motor thermistor or set of PTC motor thermistors can be connected to the PTC
terminals.
Range: Modbus Decimal Value: Default (decimal):
• Off : The SR55 will continue to operate.
• On : The SR55 will trip if the motor thermistor exceeds its
response temperature, or the PTC input is open circuit (> 4kΩ).
• 0
• 1
• Off (0)
Modbus Address: Modbus Format:
53794 ( D222 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → PTC Motor Thermistor Trip
(also Home → Advanced → Trip Settings → PTC Motor Thermistor Trip)
