Page 3–46 Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
Chapter 3: Configuration and Parameters
parameTer deTails – “i/o” menu of parameTers (ConTinued)
P10.6 – Digital Input 3 (D2-1I): High Input = 1 Sets Value Hold. Reg. Type:
Description:
Read/Write
Allows the polarity of the input to be reversed.
Range: Modbus Decimal Value: Default (decimal):
• Off : When the input is off, the selected function will be on.
• On : When the input is on, the selected function will be on.
• 0
• 1 • On (1)
Modbus Address: Modbus Format:
11268 ( 2C04 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Inputs → Digital Input 3 (D2-1I) → High Input = 1 Sets Value
digiTal inpuT funCTion seTTings
The following settings are for the “Digital Input x (x): Select Function” I/O parameters.
settings for the “Digital Input x (x): Select Function” I/O parameters 10944–10946
Settings:
Modbus
Decimal Value:
Description:
Off 0 No function selected
Start/Stop 280
• Off : Stops or Soft Stops the SR55.
• On : Starts the SR55.
Freeze Ramp 285
If set to On this parameter will hold the Start Ramp even if
“Current Irms” is less than the “Current Limit Level.”
• Off : The Soft Start Ramp is not held and the SR55 will start in
the time set.
• On : The Soft Start Ramp is held and the SR55 will take longer
than the time set to start .
Reset 287
To reset pulse high and then low.
• Off : The final state required for a reset.
• On : The initial state required for a reset.
iERS on/off 330
Enables and disables the intelligent Energy Recovery System
feature (iERS).
• Off : The feature is disabled and the motor operates at full
voltage.
• On : The voltage to the motor will be regulated to ensure
optimum efficiency.
External Trip
Command
295
Ensure start signal is low before reset.
• Off : The SR55 will not trip.
• On : If “External Trip” is enabled the SR55 trips.
To Next Page
