Automation Direct Stellar SR55 Series User Manual

Chapter 3: Configuration and Parameters
Page 3–47Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTer deTails – “i/o” menu of parameTers (ConTinued)
i/o “digiTal ouTpuTs” parameTers
P11.0 – Digital Output 1 N/C(12): Select Function Hold. Reg. Type:
Description: Read/Write
Allows the Digital Output to be mapped to different functions.
• The output will change in proportion with the selected function.
• Digital Outputs can only be user configured if the “Control Method” is set to “User
Programmable.”
Range: Modbus Decimal Value: Default (decimal):
Refer to “Digital Output Function Settings” on page 3–49. Error (583)
Modbus Address: Modbus Format:
11584 ( 2D40 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Outputs → Digital Output 1 N/C(12)) → Select Function
P11.1 – Digital Output 1 N/C(12): High Output = 1 When Value Hold. Reg. Type:
Description: Read/Write
Allows the polarity of the output to be reversed.
Range: Modbus Decimal Value: Default (decimal):
• Off : When the selected function is activated, the output is closed.
• On : When the selected function is activated, the output is open.
• 0
• 1 • On (1)
Modbus Address: Modbus Format:
11904 ( 2E80 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Outputs → Digital Output 1 N/C(12) → High Output = 1 When Value
P11.2 – Digital Output 2 N/O(24): Select Function Hold. Reg. Type:
Description: Read/Write
Allows the Digital Output to be mapped to different functions.
• The output will change in proportion with the selected function.
• Digital Outputs can only be user configured if the “Control Method” is set to “User
Programmable.”
Range: Modbus Decimal Value: Default (decimal):
Refer to “Digital Output Function Settings” on page 3–49. Error (583)
Modbus Address: Modbus Format:
11585 ( 2D41 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Outputs → Digital Output 2 N/O(24) → Select Function
P11.3 – Digital Output 2 N/O(24): High Output = 1 When Value Hold. Reg. Type:
Description: Read/Write
Allows the polarity of the output to be reversed.
Range: Modbus Decimal Value: Default (decimal):
• Off : When the selected function is activated, the output is open.
• On : When the selected function is activated, the output is closed.
• 0
• 1 • On (1)
Modbus Address: Modbus Format:
11906 ( 2E82 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Outputs → Digital Output 2 N/O(24) → High Output = 1 When Value
