Chapter 3: Configuration and Parameters
Page 3–49Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTer deTails – “i/o” menu of parameTers (ConTinued)
digiTal ouTpuT funCTion seTTings
The following settings are for the “Digital Output x (x): Select Function” I/O parameters.
settings for the “Digital Output x (x): Select Function” I/O parameters 11584–11587
Settings:
Modbus
Decimal Value:
Description:
Off 0 No function selected
Ready 581
STATUS INDICATION : Ready
Off : The SR55 has not powered up successfully or failed to reset
from a trip.
On : Indicates that the SR55 is healthy and ready for a start.
Remains on when Running.
Enabled 582
STATUS INDICATION : Enabled
• Off : The SR55 has not powered up successfully or failed to reset
from a trip
• On : Indicates that the SR55 is enabled and ready for a start.
Remains on when Running.
Error 583
STATUS INDICATION : Error
• Off : The SR55 is fault free.
• On : Indicates that SR55 has detected a fault and has shut
down.
The fault must be cleared before a reset.
Running 588
STATUS INDICATION : Running
• Off : The SR55 has detected a fault and tripped.
• On : Indicates that the motor is running and is being actively
controlled by the SR55.
End Of
Start
590
STATUS INDICATION : End Of Start
• Off : The SR55 is disabled or ramping down.
• On : Indicates that the Soft Start ramp has been completed.
Current
Limit
591
STATUS INDICATION : Current Limit
• Off : The ramp is not being held because “Current I
rms
” is less
than “Current Limit Level.”
• On : The ramp is being held because “Current I
rms
” is greater or
equal to “Current Limit Level.”
iERS Active 595
STATUS INDICATION : iERS Active
• Off : The iERS saving mode has been disabled either internally
or via “iERS.”
• On : Indicates that the SR55 is operating in the iERS energy
saving Mode.
