Page 3–48 Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
Chapter 3: Configuration and Parameters
parameTer deTails – “i/o” menu of parameTers (ConTinued)
P11.4 – Digital Output 3 N/O(34): Select Function Hold. Reg. Type:
Description: Read/Write
Allows the Digital output to be mapped to different functions.
• The output will change in proportion with the selected function.
• Digital Outputs can only be user configured if the “Control Method” is set to “User
Programmable.”
Range: Modbus Decimal Value: Default (decimal):
Refer to “Digital Output Function Settings” on page 3–49. Running (588)
Modbus Address: Modbus Format:
11586 ( 2D42 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Outputs → Digital Output 3 N/O(34) → High Output = 1 When Value
P11.5 – Digital Output 3 N/O(34): High Output = 1 When Value Hold. Reg. Type:
Description: Read/Write
Allows the polarity of the output to be reversed.
Range: Modbus Decimal Value: Default (decimal):
• Off : When the selected function is activated, the output is open.
• On : When the selected function is activated, the output is closed.
• 0
• 1 • On (1)
Modbus Address: Modbus Format:
11908 ( 2E84 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Outputs → Digital Output 3 N/O(34) → High Output = 1 When Value
P11.6 – Digital Output 4 N/O(44): Select Function Hold. Reg. Type:
Description: Read/Write
Allows the Digital output to be mapped to different functions.
• The output will change in proportion with the selected function.
• Digital Outputs can only be user configured if the “Control Method” is set to “User
Programmable.”
Range: Modbus Decimal Value: Default (decimal):
Refer to “Digital Output Function Settings” on page 3–49. End of Start (590)
Modbus Address: Modbus Format:
11587 ( 2D43 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Outputs → Digital Output 4 N/O(44) → Select Function
P11.7 – Digital Output 4 N/O(44): High Output = 1 When Value Hold. Reg. Type:
Description: Read/Write
Allows the polarity of the output to be reversed.
Range: Modbus Decimal Value: Default (decimal):
• Off : When the selected function is activated, the output is open.
• On : When the selected function is activated, the output is closed.
• 0
• 1 • On (1)
Modbus Address: Modbus Format:
11910 ( 2E86 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Outputs → Digital Output 4 N/O(44) → High Output = 1 When Value
