Automation Direct Stellar SR55 Series User Manual

Chapter 3: Configuration and Parameters
Page 3–45Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTer deTails – “i/o” menu of parameTers (ConTinued)
P10.2 – Digital Input 1 (D1-1I): High Input = 1 Sets Value Hold. Reg. Type:
Description: Read/Write
Allows the polarity of the input to be reversed.
Range: Modbus Decimal Value: Default (decimal):
• Off : When the input is off, the selected function will be on.
• On : When the input is on, the selected function will be on.
• 0
• 1 • On (1)
Modbus Address: Modbus Format:
11264 ( 2C00 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Inputs → Digital Input 1 (D1-1I) → High Input = 1 Sets Value
P10.3 – Digital Input 2 (D1-2I): Select Function Hold. Reg. Type:
Description: Read/Write
Allows the Digital Input to be mapped to different functions.
• The selected function will change in proportion with the input.
• Digital Inputs can only be user configured if “Control Method” is set to “User Programmable.”
• All Digital Inputs are disabled if “Control Method” is set to “Local Touch Screen” or “Modbus
Network.”
Range: Modbus Decimal Value: Default (decimal):
Refer to “Digital Input Function Settings” on page 3–46. Off (0)
Modbus Address: Modbus Format:
10945 ( 2AC1 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Inputs → Digital Input 2 (D1-2I) → Select Function
P10.4 – Digital Input 2 (D1-2I): High Input = 1 Sets Value Hold. Reg. Type:
Description: Read/Write
Allows the polarity of the input to be reversed.
Range: Modbus Decimal Value: Default (decimal):
• Off : When the input is off, the selected function will be on.
• On : When the input is on, the selected function will be on.
• 0
• 1 • On (1)
Modbus Address: Modbus Format:
11266 ( 2C02 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Inputs → Digital Input 2 (D1-2I) → High Input = 1 Sets Value
P10.5 – Digital Input 3 (D2-1I): Select Function Hold. Reg. Type:
Description: Read/Write
Allows the Digital Input to be mapped to different functions.
• The selected function will change in proportion with the input.
• Digital Inputs can only be user configured if “Control Method” is set to “User Programmable.”
• All Digital Inputs are disabled if “Control Method” is set to “Local Touch Screen” or “Modbus
Network.”
Range: Modbus Decimal Value: Default (decimal):
Refer to “Digital Input Function Settings” on page 3–46. Reset (287)
Modbus Address: Modbus Format:
10946 ( 2AC2 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → I/O → Digital Inputs → Digital Input 3 (D2-1I) → Select Function
