Page 3–8 Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
Chapter 3: Configuration and Parameters
Summary – Parameters for Touchscreen Setup – “Advanced” Category (continued)
– Group Parameter Units Range
Read /
Write
Modbus
Default
Setting
User
Setting
Address Hex
Category – Advanced
(P5)
Motor
Protection
[detailed info
starts page
3–29]
P5�0 – Motor Current A 10% to 100% of SR55 rated A R/W 25728 6480 100%
P5�1 – Trip Class class 10, 20, 30 R/W 25664 6440 10
Low Current Settings →
P5�2 – Low Current Trip
toggle OFF / ON R/W 53787 D21B OFF
Low Current Settings →
P5�3 – Low Current Trip Level
A 25% to 100% of motor FLA R/W 26304 66C0 25%
Low Current Settings →
P5�4 – Low Current Trip Time
ms 100 to 9,000 R/W 26368 6700 100
Shearpin Settings →
P5�5 – Shearpin Trip
toggle OFF / ON R/W 53793 D221 ON
Shearpin Settings →
P5�6 – Shearpin Trip Current
A
100% mtr FLA to
450% SR55 rated A
R/W 27584 6BC0
450%
SR55 A
Shearpin Settings →
P5�7 – Shearpin Trip Time
ms 100 to 9,000 R/W 27648 6C00 100
Overload Settings →
P5�8 – Overload Trip
toggle OFF / ON R/W 53792 D220 ON
Overload Settings →
P5�9 – Overload Level
A 50% to 125% of motor FLA R/W 28224 6E40 115%
(P6)
iERS
[detailed info
starts page
3–32]
P6�0 – iERS toggle OFF / ON R/W 21120 5280 ON *
P6�1 – Dwell Time s 1 to 300 R/W 7360 1CC0 5
P6�2 – iERS Rate % 0 to 100 R/W 21184 52C0 25
P6�3 – iERS Level % 0 to 100 R/W 21376 5380 100
P6�4 – Fixed Voltage (Level) V 100 to 500 R/W 35200 8980 500
P6�5 – Fixed Voltage toggle OFF / ON R/W 35264 89C0 OFF
* NOTE: iERS (P6.0) default setting is “OFF” beginning in firmware version 59.35.
(P7)
[detailed info
page 3–21]
P7�0 – Control Method –
Local Touch Screen
User Programmable
Two Wire Control
Three Wire Control
Modbus Network
R/W 59392 E800
Local
Touch
Screen
(P8)
Trip Settings
[detailed info
starts page
3–35]
P8�0 – Trip Sensitivity % 0 to 100 R/W 44864 AF40 0
P8�1 – Cover Open Trip toggle OFF / ON R/W 53803 D22B OFF
P8�2 – Shearpin Trip toggle OFF / ON R/W 53793 D221 ON
P8�3 – Overload Trip toggle OFF / ON R/W 53792 D220 ON
P8�4 – Low Current Trip toggle OFF / ON R/W 53787 D21B OFF
P8�5 – Start Current Limit Trip toggle OFF / ON R/W 53790 D21E ON
P8�6 – Stop Current Limit Trip toggle OFF / ON R/W 53791 D21F OFF
P8�7 –
PTC Motor Thermistor Trip
toggle OFF / ON R/W 53794 D222 OFF
P8�8 – L1-L2-L3 Trip toggle OFF / ON R/W 53808 D230 OFF
P8�9 – L1-L3-L2 Trip toggle OFF / ON R/W 53807 D22F OFF
P8�10 – Remote Start Trip toggle OFF / ON R/W 53804 D22C ON
P8�11 – Current Sensor Trip toggle OFF / ON R/W 53775 D20F OFF
P8�12 – Fan Trip toggle OFF / ON R/W 53782 D216 ON
P8�13 – Communications Trip toggle OFF / ON R/W 53796 D224 ON
P8�14 – Shut Down (1) toggle OFF / ON R/W 53769 D209 ON
P8�15 – Shut Down (2) toggle OFF / ON R/W 53770 D20A ON
P8�16 – Thyristor Firing Trip toggle OFF / ON R/W 53774 D20E ON
P8�17 – Motor Side Phase Loss toggle OFF / ON R/W 53777 D211 ON
P8�18 – Sensing Fault Trip toggle OFF / ON R/W 53781 D215 ON
P8�19 – Thermal Sensor Trip toggle OFF / ON R/W 53768 D208 ON
P8�20 – External Trip Enable toggle OFF / ON R/W 53795 D223 OFF
P8�21 – Main Board Trip toggle OFF / ON R/W 53800 D228 ON
P8�22 – Keypad Trip toggle OFF / ON R/W 53798 D226 OFF
P8�23 – Logging Trip toggle OFF / ON R/W 53799 D227 OFF
P8�24 – Input Side Phase Loss toggle OFF / ON R/W 53762 D202 ON
