Automation Direct Stellar SR55 Series User Manual

Chapter 3: Configuration and Parameters
Page 3–23Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTer deTails – “advanCed” menu of parameTers (ConTinued)
P2.3 – Automatic Stop Hold. Reg. Type:
Description: Read/Write
Automatically controls the soft stop to suit the application.
This feature is particularly useful with pumping applications
Range: Modbus Decimal Value: Default (decimal):
• Off : The deceleration to the point where the soft stop becomes
useful will be slower.
• On : If the motor is lightly loaded it decelerates rapidly to the
point where the soft stop becomes useful.
• 0
• 1
• Off (0)
Modbus Address: Modbus Format:
20160 ( 4EC0 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → Automatic Settings → Automatic Stop
P2.4 – Automatic Stop Profile Type:
Description: Read/Write
Adjusts the response of the “Automatic Stop.”
• Increase if the motor speed doesn’t drop quickly enough.
• When the value is set to zero, the “Automatic Stop” is effectively disabled.
Range: Modbus Decimal Value: Default:
0% – 100% linear scale ( 1 = 0.006104 % )
0% – 100% = (0 – 16384)
x% / 0.006104% = Modbus dec. value
EX: Modbus value of 2900 = 17.7016%
50%
Modbus Address: Modbus Format:
20608 ( 5080 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → Automatic Settings → Automatic Stop Profile
P2.5 – Automatic End Stop Hold. Reg. Type:
Description: Read/Write
Automatically controls the “Stop Time.”
Range: Modbus Decimal Value: Default (decimal):
• Off : The ramp time depends on the “Stop Time” and “Current
Limit.”
• On : The ramp time is shortened if the motor reaches a very low
speed before the end of the “Stop Time.”
• 0
• 1
• Off (0)
Modbus Address: Modbus Format:
20416 ( 4FC0 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → Automatic Settings → Automatic End Stop
P2.6 – Automatic Impact Load Hold. Reg. Type:
Description: Read/Write
Automatically controls the maximum iERS saving level.
Range: Modbus Decimal Value: Default (decimal):
• Off : The saving potential may be reduced on applications with
heavy load cycles , such as injection molding machines.
• On : The maximum iERS saving level (“BackStop” ) is reset to
maximum during each load cycle.
• 0
• 1
• Off (0)
Modbus Address: Modbus Format:
20480 ( 5000 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → Automatic Settings → Automatic Impact Load
