6.Parametersettingandfunctions
28
©CopyrightReservedAutonicsCo.,Ltd.
Input 4mA 8mA 12mA 16mA 20mA
MV 0% 25% 50% 75% 100%
Display voltage
(static voltage control)
0.0 55.0 110.0 165.0 220.0
Display voltage
(static current control)
0.0 12.5 25.0 37.5 50.0
(3)RMSdisplay
This unit measures and displays RMS for accuracy.
At pure resistance load, in normal control, when input is 4-20mA and rating is 220V, it displays as
below.
In case of static voltage or static current, voltage and current displays as below.
Input 4mA 8mA 12mA 16mA 20mA
MV 0% 25% 50% 75% 100%
Display
voltage
0.0V 70V 155.5V 209.7V 220.0V
