5.Installationandinitialoperation
5.1 Installation
Turn OFF the main power and open the front cover.
Wire it according to the connection diagrams.
5.2 Initialdisplay
When turning ON the power to the unit, front displays ash for 1 sec and it displays product
version, rated voltage, rated current and operates RUN mode.
5.1 Installation
5.3.1 Parameters
Mode Descriptions
Monitoring Mode
Monitors input value, load voltage/current/power/resistance, power
frequency.
Operating Mode[
OP
] Sets parameters for DPU operation
Setting Mode 1[
ST-1
] Sets parameters for details set.
Setting Mode 2[
ST-2
] Sets parameters for alarm
①
Whole ashes
②
Displays
product version
③
Displays rated
voltage
④
Displays rated
current
⑤
RUN mode
ST-2ST-1OP
key for 1 sec.
key for 3 sec.
Monitoring
mode
Operating mode Setting mode 1 Setting mode 2
RUN
mode
