6.Parametersettingandfunctions
41
©CopyrightReservedAutonicsCo.,Ltd.
6.2.15 Fullloadautorecognition[
F-LD
]
When operating load recognition function, it outputs 100% for 3 sec. Do not use this unit to the
device which has problem 100% output of load.
Set
F-LD
as
ON
in Setting Mode 1 [
ST-1
] group and press the
key, load auto recognition
function operates. According to secular changes of the load, execute this function regularly.
When using special load such as (super) tantalum, SiC, molybdenum, tungsten, [
H-BK
] alarm
clear method:
• Set load resistance display method [
DRES
] as
UP
in Setting Mode 1 [
ST-1
].
• Set heater disconnect alarm value [
HB-V
] as
500
in Setting Mode 2 [
ST-2
].
Do not execute this function as
ON
without profession’s consultations. When executing this
function, voltage, current outputs fully. Be sure that it may cause damage to the load.
When using special load using low voltage and high current such as (super)tantalum, SiC,
molybdenum, tungsten, etc, it may cause heater disconnect alarm [
H-BK
].
This alarm does not have problem in operation but it occurs when it does not detect the load
when using as low voltage. Set the below notes to clear the alarm.
Be sure that when auto recognition starts, it operates 100% output for 3 sec.
: Enable to check and set, : Enable to check/Disable to set, X: Disable to check
OFF LOC1 LOC2 LOC3
Operating Mode set group
Setting Mode 2 set group
Setting Mode 1 set group X X
6.2.16 Parameterlock[
LOCK
]
This function is to limit parameter set value check and change.
