6.3 Alarm
※
1: When it cannot return by re-supplying power because fuse is disconnected or element is
error, refer to ‘8. Maintenance’.
6.3.1 Overcurrent alarm [
OC-A
]
When overcurrent alarm occurs, output stops and alarm maintains. [
O-C
] ashes for 0.5 sec in the
display part and the EVT indicator ashes for 0.5 sec.
When setting as [
NON
], alarm output does not occur but [
O-C
] ashes.
Alarm clears when re-supplying power, reset, or stop the unit.
(1) Overcurrent alarm value setting [
OC-U
]
Set overcurrent alarm value within 0.0 to 120.0% of rated current range.
(2) Overcurrent alarm delay time [
OC-T
]
Set overcurrent alarm delay time within 0 to 100 sec. range. After the set time, over current alarm
occurs.
6.3.2 Current limit [
C-LM
]
This function limits current when using big inrush load to protect thyristor.
Especially for voltage feedback, current for load resistance value ows and it may over the rated
thyristor only voltage control. Therefore, it limits current to prevent over the rated current.
• Set range: 0 to 110% (unit: %)
Alarm Display Operation in alarm Alarm clear
Overcurrent alarm
O-C
Stops output
(SCR OFF)
•
Re-supply the power.
•
RESET (
key)
•
Switch to STOP mode
Overvoltage alarm
O-V
Fuse break alarm
FUSE
Heatsink overheat alarm
TEMP
Element error alarm
SCR
Heater break alarm
H-BK
Continues operation
Automatically cleared within
the set range
※
1
※
1
