Installation Manual Page 5
IP Office 2.1 40DHB0002USCL Issue 10c (11th May 2004)
IP401 Compact Office Platform
IP401 Compact Office
The IP401 Compact Office system platform is supplied in two variants:
• IP401 Compact Office 2 supports: Two digital and two analog telephones A BRI ISDN port (2
trunks) An four port auto-negotiating 10/100 BaseT LAN hub.
• IP401 Compact Office 4 supports: Four digital and four analog telephones Two BRI ISDN
ports (4 trunks) An eight port auto-negotiating 10/100 BaseT LAN hub. The IP401 Compact
Office 2 can be expanded to an IP401 Compact Office 4.
See IP400 Office Systems
for country specific variants.
The auto-negotiating 10/100 BaseT LAN hub provides access to networks and/or up to eight IP
telephones.
The DT ports support Avaya 2000 series telephones. DT ports are set to A-Law PCM encoding at default
but can be programmed to -Law PCM encoding.
In addition the IP401 Compact Office can be fitted with any of the following optional Integral Modules:
• WAN Port
This port supports a single synchronous data connection, which can be X.21, V.35 or V.24.
• Voice Compression Module (VCM5)
Supports VoIP applications (over two of the five channels) using Avaya 4600 IP telephones
connected via LAN ports.
• VME card
Provides memory capacity for embedded voice mail feature.
