Scenario 2
A business requiring 180 analog Telephones and 60 lines.
The configuration illustrates a fully configured IP406 Office providing 180 extensions and 60 trunks.
Factory shipped with a single PRI the system is fitted with an extra trunk card in its spare slot to provide
the additional 30 lines.
Kit List
• IP406 Office PRI 30 E1 fitted with an additional IP400 IP PRI E1 trunk card
• 6 x IP400 Office Phone Module 30
