Configuring the 802.11b/g and IP Settings 2-5
IP Gateway
The IP Gateway (or router) allows connections (communications)
between different subnets on a network. It consists of four 3-digit
numeric fields.
To change the setting, from the Main Menu: Select Setup, Network.
Then follow these steps.
1. Press or until you see
NETWORK
IP Gateway
2. Press Enter/Pause. The current setting is displayed, for example:
Gateway Address
010.192.000.000
3. Press or to move through the positions. Press Feed/Cut to
scroll one digit at a time from 0-9. After you display the option you
need, press Enter/Pause.
For example, to change the Gateway Address from 192 to 000,
press or to highlight the first position and press Feed/Cut
until you see 0
, then press to select the next position and
press Feed/Cut until you see 0
, then press to select the next
position and press Feed/Cut until you see 0
. Press Enter/Pause
to save the setting or press Escape/Clear to exit without saving.
If you enter a series of digits greater than 255 for any segment of
the Gateway Address and press Enter/Pause, the printer does
not save the setting and no error appears on the display. Correct
the Gateway Address and then press Enter/Pause to save the
setting.
4. Press Escape/Clear until you see the Main Menu.
