Guide Bar Assy., Feed Assy. and Feed Lever Assy. Spare Parts List:
Item P/N Description Qty.
240 3-06-0019-01 Assy, Guide Bar 1
241 3-05-0035-01 Guide Bar, Staple 1
242 3-05-0036-01 Plate, Guide 1
243 DT0133-001 Guide, L-shaped Staple 1
244 140001001201 Screw, Hexagon Socket Cup Head, Black 4X10
4
245 140012008001 Lock Washer, Black D4 4
246 140012012101 Washer, Black D4 4
247 140001000802 Screw, Hexagon Socket Cup Head, Black 3X6 2
248 140012007901 Lock Washer, Black D3 2
249 140012012201 Washer, Black D3 2
250 3-06-0020-01 Assy, Feed 1
251 3-05-0037-01 Plate, Support, Left 1
252 3-05-0038-01 Shaft, Feed 1
253 3-05-0039-01 Ratchet, Feed 1
254 3-05-0040-01 Clutch, Feed 2
255 3-05-0041-01 Gear, Feed 1
256 3-05-0042-01 Handle, Feed 1
257 DT0163-001 Post, Tension Spring 1
258 DT0137-001 Collar, Feed 1
259 DT0140-001 Key 1
260 DT0145-001 Plate, Support, Right 1
261 110013021701 Roller bearing, one way 1
262 110016038101 Spring, Pawl 1
263 110016038201 Spring, Feed 1
264 110017000101 C Ring, Shaft 1
265 140004000702 Trip Bolt, Hexagon Socket Head, Black 3X5 2
266 140003005402
Screw, Hexagon Socket Countersunk Head,
Black 3X8
2
267 140001000602 Screw, Hexagon Socket Cup Head, Black 3X30
2
268 140012007901 Lock Washer, Black D3 2
269 140001001201 Screw, Hexagon Socket Cup Head, Black 4X10
4
270 140012008001 Lock Washer, Black D4 4
271 140012008601 Washer, Black D6 1
272 3-06-0021-01 Assy, Lever Feed 1
273 3-05-0043-01 Lever, Feed 1
274 3-05-0044-01 Pawl, Feed 1
275 DT0156-001 Spacer 6 2
276 140001063901 Screw, Hexagon Socket Cup Head, Black 4X14
2
277 140012012101 Washer, Black D4 3
278 140012008001 Lock Washer, Black D4 2
To Next Page
