Model E1070 Indicator Service Manual
8. Press the PRINT key to perform a dynamic test of the display. . .
Display lights all digits and annunciators and continues to flash.
9. Press ESC key to stop the dynamic test.
10. Press the UNITS key. . .
BUTTON is displayed. This is the button test item.
11. Press the PRINT key to perform a button test. Each key you press will
be reflected on the display screen to confirm the button is functioning
correctly. The ESC key is excluded from this test. It is used to stop the
testing and return to the menu item
12. Press ESC key to stop the button test.
BUTTON is displayed.
13. Press the UNITS key. . .
SERIAL is displayed. This is the serial test item.
14. Press the PRINT key to access the serial test.
PORT1 is displayed. If you jumper the transmit and receive lines
on the serial port and press the PRINT key, the display should
show PASS. If there is a problem the display will show FAIL.
Repeat this for PORT 2.
15. Press the SELECT key to exit the serial test.
SERIAL is displayed.
16. Press the SELECT key. . .
TEST is displayed.
17. Press the UNITS key. . .
AUDIT is displayed.
18. Press the PRINT key. . .
CFG is displayed. This stands for the configuration audit counter.
19. Press the PRINT key to see the number of times the configuration has
been altered on this indicator.
20. Press the SELECT or ENTER key. . .
CFG is displayed.
21. Press the UNITS key. . .
CAL is displayed. This stands for the calibration audit counter.
22. Press the PRINT key. . .
The number of times the indicator has been calibrated is dis-
played.
23. Press ESC twice to return to normal operation mode
This completes the User menu.
Calibration and configuration
counters cannot be reset.
User Menu—(continued)
