Model E1070 Indicator Service Manual
Annunciators
There are several annunciators around the edge of the display. The illustra-
tion below explains each one.
Preset Tare
Network &
SensorComm
status
Accumulator,
Count
Output 3
Output 2
Output 1
Print
Tare weight
Net weight
Center of zero
Motion
Gross weight
Checkweighing
graph
Pound
Kilogram
Custom Unit
Center of Zero Lights when weight on the scale is within the zero range
Motion Lights during scale motion.
Gross Lights when gross weight is displayed
Net Lights when net weight is displayed
Tare Lights when tare weight is displayed
Print Lights when print format sent through serial port
OP 1 Lights when output one is activated
OP 2 Lights when output two is activated
OP 3 Lights when output three is activated
PT Lights when preset tare is active
Network & This is configurable to light to show status of the Net
SensorComm work 1, Network 2 or SensorComm. See note at left.
Status
Accumulator, Lights when an accumulation occurs and while in the
Count count and peak applications
Custom Unit Lights when a custom unit of measure is active
KG Lights when kilograms is the active unit of measure
LB Lights when pounds is the active unit of measure
Checkweigher Lights when checkweighing application is active
Bottom LED color
SCOM:
Red – a cell has been ghosted.
Check the ghost log.
Green – a sensorcomm error
has occurred. Check the error
log.
Off – Scale is functioning
normally.
Network 1 or 2:
Red – A network error has
occurred. Check the network
settings on the indicator and
PLC, and reboot the indicator.
Green – The network connec-
tion has been established.
Amber – The network is ready
for a connection, but no
connection has been estab-
lished.
