Model E1070 Indicator Service Manual
SCALE submenu
Use this section of the Service menu for scale configuration. Figure 5 shows
the flowchart of this menu item. Follow the directions and explanations
below to set up these items.
Figure 5
Scale submenu flowchart
Source
(Analog or SensorComm)
1. Continue from previous step 4a or access the Service menu. . .
CAL is displayed.
2. Press the UNITS key. . .
SCALE is displayed.
3. Press the PRINT key. . .
SOURCE is displayed. Use this item to choose between an
analog or SensorComm based system.
4. Press the PRINT key. . .
The current setting is displayed.
5. Toggle between the Analog and Scom (North America only) choices
using the TARE or UNITS key. When your choice is displayed press the
ENTER key. . .
SOURCE is displayed.
Calibration instructions for
Analog scales are in the
section—CAL submenu for
analog scales
Calibration instructions for
SensorComm scales are in the
section—CAL submenu for
SensorComm scales
