Model E1070 Indicator Service Manual
Error Messages
The following are displays you may see if problems occur or if invalid
operations are attempted with your indicator:
Display Description
Overrange weight.
Underrange weight.
The unit cannot perform a function. Displayed only while
key is held down.
Displayed while a key is pressed when attempting to
modify a sealed selection without edit privileges.
When you are in the Linearity menu item in the Service menu, you may see
the following errors:
Display Description
Out of ascending order
Value <1% of capacity
Value causes resolution >100,000 divisions
When you are in the Span menu item in the Service menu, you may see the
following errors:
Display Description
Entered value > set capacity
Value <1% of capacity
Value causes resolution >100,000 divisions
All these relate to mV/V input
No ADC counts OR
in Overload OR
in Underload
