54
Model E1070 Indicator Service Manual
The next section of the Service menu is the OUTPUT submenu. See Figure
12. This menu lets you configure the outputs of the indicator. Outputs must
be enabled to use the cutoff (trips) operation in each of the applications. If
the batch application is enabled, outputs are automatically enabled.
OUTPUT submenu
Figure 12
OUTPUT submenu
Follow these steps to access and configure the outputs:
1. Access the Service menu. . .
CAL is displayed.
2. Press the UNITS key repeatedly until. . .
OUTPUT is displayed.
3. Press the PRINT key. . .
1 is displayed. This stands for output #1. You can scroll to each
output by using the TARE or UNITS key. Access each output, by
pressing the PRINT key, and enable or disable the output by
selecting ON or OFF.
4. Toggle between ON and OFF by using the TARE or UNITS key and
press the ENTER key to accept the displayed choice. . .
The output #is displayed. Repeat for the other outputs.
5. Press the SELECT key to return to the OUTPUT menu item. . .
OUTPUT is displayed.
