Model E1070 Indicator Service Manual
Keys
The functions of the keys on the front panel are listed below.
Never press a key with any-
thing but your finger. Damage
to the overlay may result if
sharp or rough objects are
used.
Press the TARE key to perform a tare function. Also acts as a
left arrow key when in the menus.
Press the SELECT key to toggle between Gross, Tare, Net,
Count, Gross Accumulator, Net Accumulator, Transaction
Counter, Piece Weight, and Peak. Dependent on the current
application. Also acts as an up arrow key when in the menus.
Press the ZERO key to zero the display.
Press the PRINT key to send information to a peripheral device
through the Comm port. Also acts as a down arrow key when in
the menus.
Press the UNITS key to scroll through the available units of
measure while in normal operating mode. Also acts as a right
arrow key when in the menus.
Press the F1 key to select application specific choices. Press
and hold to access the cutoffs (trips) function. Also used to
access PLU memory channels.
Use the numeric keypad to enter values.
Press the C/CE key to clear entries.
Press the MODE key to scroll through the activated applica-
tions. Press and hold for 3-5 seconds to see the name of the
currently active application.
Press the ESC key to escape a function or return to normal
operation mode.
Press the ENTER key to accept displayed choices.
Press and release the ON/OFF key to turn the unit on. Press
and hold the key until the unit turns off.
