Avery Weigh-Tronix evolution Series - User Menu

10
Model E1070 Indicator Service Manual
User Menu
The User menu lets you test various functions of the indicator. The User
menu is shown in Figure 2.
Figure 2
User menu flowchart
Following are specific instructions for the User menu.
1. Access the User menu by pressing and holding the ESC key for 3-5
seconds.
PASS_ is displayed.
2. Key in the User menu password (111) and press ENTER.
TEST is displayed.
3. Press the PRINT key.
ABOUT is displayed. Press the PRINT key then the UNITS key to
view the part number and revision level for the software found in
your indicator.
Press SELECT key to return to ABOUT.
4. Press the UNITS key. . .
ADC is displayed. This stands for the analog to digital converter
value in mV/Vs.
5. Press the PRINT key. . .
The mV/V value coming into the indicator is displayed. This should
change as weight on the scale changes.
6. Press the SELECT. . .
ADC is displayed.
7. Press the UNITS key. . .
DISP is displayed. This is the display test item.
While in a menu, the fan
graphs at the top of the display
flash as a reminder.
