52
Model E1070 Indicator Service Manual
The next section of the Service menu is the INPUT submenu. See Figure
11. This menu lets you configure the inputs of the indicator.
INPUT submenu
Figure 11
INPUT submenu
Follow these steps to access and configure the inputs:
1. Access the Service menu. . .
CAL is displayed.
2. Press the UNITS key repeatedly until. . .
INPUT is displayed.
3. Press the PRINT key. . .
1 is displayed. This stands for input #1. You can scroll to each
input by using the TARE or UNITS key. When you access each
input, by pressing the PRINT key, you get to choose from this list
of input types:
NONE Input does nothing
ZERO Input zeroes the scale
TARE Input tares the scale
PRINT Input causes the print function to occur
UNITS Input toggles the unit of measure
F1KEY Input performs current F1 function
T.CNCEL Input clears the tare
START Starts a batch/fill if the batching application is active
STOP Stops a batch/fill if the batching application is active
