Avery Weigh-Tronix evolution Series - Page 15

15
Model E1070 Indicator Service Manual
DISP
(Live Weight Display)
1. From previous step 9 press the UNITS key. . .
DISP is displayed. Use this item to view the live weight on the
scale without exiting the Service menu.
2. Press the PRINT key. . .
The live weight is displayed.
3a. Press the SELECT key. . .
DISP. is displayed.
OR
3b. Press the SELECT key to move to the top of the Service menu. . .
CAL is displayed.
1. From previous step 3a, press the UNITS key. . .
PRINT is displayed. This item lets you print a calibration report.
The information printed can be very useful if you have service
issues later.
2. Press the PRINT key. . .
PORT 1 is displayed. The other choice is PORT 2. This allows you
to choose a port through which the calibration report is printed.
3. Toggle between the choices using the TARE or UNITS key and press
ENTER when your choice is displayed. . .
The report is printed and the display returns to PRINT.
4a. Press the SELECT key to return to the CAL item of the Service menu
and continue with the Service menu instructions in the next section
OR
4b. Press the ESC key to return to normal operation mode.
SAVE is displayed.
5. Press the ENTER key to save changes or press the ESC key to exit the
menu without saving.
This completes the CAL section of the Service menu for analog scales. If
you have a SensorComm system, see the section SensorComm Hardware
Configuration and Calibration for calibration and configuration information.
The next Service menu item, SCALE, is covered in the SCALE Submenu
section.
PRINT
(Print a Calibration Report)
Service Menu—Analog CAL submenu (continued)
