Model E1070 Indicator Service Manual
ODVA™, Ethernet/IP™ and DeviceNet™ are trademarks of ODVA.
PROFIBUS
®
is a registered trademark of PROFIBUS International.
Specifications
Power requirements
• 85-265 Volts AC @ 0.3Amp maximum
• 50/60 Hz
Excitation
• +/- 5 volts DC
• Supports up to eight 350-ohm weight sensors
Analog signal input range
• +/-60 mV
Analog signal sensitivity
• 0.2 µV/V/divisions minimum
• 1.0 µV/V/divisions recommended
Calibration
2 to 5 points stored
Operational keys
• Twenty-two keys: Tare, Select, Zero, Print, Units,
F1, Clear, Mode, Escape, Enter, On/Off, Decimal,
0-9 numeric
Operational annunciators
• Center of Zero, Motion, Gross, Net, Tare,
• Under/Target//Over
• Units of measure (LB, KG)
• Print, OP1, OP2, OP3, Pt Tare
Display
• Six-digit, seven-segment, 0.8-inch high, LED
Display rate
• Selectable (1, 2, 5, 10)
Analog to digital conversion rate
• 100 times per second
Unit of measure
• Pounds, kilograms, custom
Capacity selections
• 999,999 with decimal located from zero to five
places
Incremental selections
• Multiples and sub-multiples of 1, 2, 5
Programmable selections
• Zero range, motion detection, automatic zero
tracking, five-point linearization.
Time and date/RAM
• Battery backed up real time clock and RAM
standard
Internal resolution
• 53,687,100 counts per mV/V per second
Harmonizer™ digital filtering
• Fully programmable to ignore noise and vibration
Standard inputs
• Three logic level inputs for: Zero, Print, Tare,
Units, F1, Start and Stop
Standard outputs
• 10/100 Ethernet (Modbus/TCP, TCP/IP, SMTP,
DHCP, Ethernet/IP)
• PROFIBUS DP
• DeviceNet
• Two serial ports
• RS-232/422/485 (SensorComm) selectable
• RS232 or 20mA current loop
• Three cutoff outputs
Serial Command Inputs/Outputs
• Programmable serial response to ASCII character
input
• SMA protocol, Broadcast
Self diagnostics
• Display, keys, inputs, outputs, serial port, A to D
converter
Circuitry protection
• RFI, EMI, and ESD protection
Options
• Analog output/Pulse input
• ControlNet
TM
• TIU3
• Remote I/O
Operating applications
• General weighing with accumulation,
Batching, Counting, Checkweighing, Peak
measurement, Remote display
Operating temperature
• 14 to 104° F (-10 to 40° C) approved
• -40 to 140° F (-40 to 60° C) non-legal
• Up to 95% non-condensing humidity
Enclosure
• Stainless steel NEMA 6/4X
Dimensions
• 9.25" W x 9.25" H x 4.5" D (without mounting
bracket)
• 9.75" W x 11" H x 7" D (with mounting bracket)
Weight
• 8.5 lb, 4 kg
Agencies
• NTEP CC#04-031 Class III/IIIL:10,000 divisions
• OIML pending
• Canadian Weights and Measures pending
• UL/CUL
• CE marked
