I/O Setup
Configure the Pro Tools I/O Setup for input and output routing for Pro Tools | Carbon.
Pro Tools | Carbon Input Setup
Pro Tools | Carbon provides Mic, Line, Instrument, ADAT, and Talkback mic inputs.
At higher sample rates, the number of available ADAT Inputs and Outputs are reduced for each port. At 88.2/96 kHz, only
ADAT channels 1–4 are available, and at 176.4/192 kHz, only ADAT channels 1–2 are available. Unavailable ADAT chan-
nels are indicated in italic text in the Input, Output, Bus, and Insert pages of the I/O Setup.
I/O Setup, Input page (default Input configuration for Pro Tools | Carbon using the Stereo format)
