Appendix A: Specifications 36
Appendix A: Specifications
Audio Specifications
Microphone Preamp Inputs
Line Inputs
Back panel: XLR inputs 1–8
Frequency Response 20 Hz to 20 kHz, ±0.1 dB
Gain Range 3–60 dB in 1 dB steps
Equivalent Input Noise (EIN) –129 dBu (A-weighted)
Signal to Noise Ratio (SNR) –123.5 dB, –126 dB (A-weighted)
Dynamic Range 126 dB (A-weighted)
Total Harmonic Distortion (THD) 1 kHz @ –1 dBFS –105 dB (0.00056%)
Maximum Input Level +24 dBu
Crosstalk –145 dB @ 1 kHz
Phantom Power +48V
Connector Type 8 XLR (XLR/TRS Combo)
Back panel: DB25 inputs 1–8 and 1/4-inch TRS inputs 1–8
Frequency Response 20 Hz to 20 kHz, ±0.1 dB
Gain Range 6–60 dB in 1 dB steps
SNR –122 dB, –125 dB (A-weighted)
Dynamic Range 123 dB, 125 dB (A-weighted)
THD 1 kHz @ –1 dBFS –106 dB (0.0005%)
Maximum Input Level +24 dBu
Crosstalk –145 dB @ 1 kHz
Connector Type 1/4-inch TRS Balanced (Combo XLR/TRS)
DB25 (Tascam wiring), normalled
