Appendix A: Specifications 37
Line Inputs (True Bypass)
Instrument Inputs
Line Outputs
Back panel: DB25 inputs 1–8 and 1/4-inch TRS inputs 1–8
Frequency Response 20 Hz to 20 kHz, ±0.1 dB
Gain Range 0 dB fixed
SNR –123 dB, –126 dB (A-weighted)
Dynamic Range 123 dB, 126 dB (A-weighted)
THD 1 kHz @ –1 dBFS –113 dB (0.00022%)
Maximum Input Level +24 dBu
Crosstalk –145 dB @ 1 kHz
Connector Type 1/4-inch TRS Balanced (Combo XLR/TRS)
DB25 (Tascam wiring), normalled
Front panel 1/4-inch TS inputs 1–2
Frequency Response 20 Hz to 20 kHz, ±0.1 dB
Gain Range 3–60 dB in 1 dB steps
SNR –120 dB, –122 dB (A-weighted)
Dynamic Range 123 dB, 125 dB (A-weighted)
THD 1 kHz @ –1 dBFS –103 dB (0.0007%)
Maximum Input Level +15.7 dBV
Crosstalk –145 dB @ 1 kHz
Connector Type 1/4-inch TS Unbalanced
Back panel DB25 outputs 1–8
Frequency Response 20 Hz to 20 kHz, ±0.1 dB
SNR –120 dB (A-weighted)
Dynamic Range 120 dB (A-weighted)
THD 1 kHz @ –1 dBFS –110 dB (0.0003%)
Maximum Output Level +24 dBu
Crosstalk –135 dB @ 1 kHz
Connector Type DB25 (Tascam wiring)
