AVB Channel to Physical I/O Mappings for the Pro Tools | Carbon: I/O Device
The following table is for the Pro Tools | Carbon: I/O device with these AVB configurations:
• 28x56 (44.1–96 kHz)
• 56x56 (44.1–96 kHz)
• 56x84 (44.1–96 kHz)
AVB Channels
44.1–48 kHz 88.2–96 kHz
AVB In 1–28 AVB Out 1–28 AVB In 1–28 AVB Out 1–28
Pro Tools | Carbon I/O Pro Tools | Carbon I/O
In 1–28 Out 1–28 In 1–28 Out 1–28
1–2 Mic/Line/Inst 1–2 Mon L–R Mic/Line/Inst 1–2 Mon L–R
3–4 Mic/Line 3–4 Line 1–2 Mic/Line 3–4 Line 1–2
5–6 Mic/Line 5–6 Line 3–4 Mic/Line 5–6 Line 3–4
7–8 Mic/Line 7–8 Line 5–6 Mic/Line 7–8 Line 5–6
9–10 ADAT 1 1–2 Line 7–8 ADAT 1 1–2 Line 7–8
11–12 ADAT 1 3–4 HP 1 ADAT 1 3–4 HP 1
13–14 ADAT 1 5–6 HP 2 — HP 2
15–16 ADAT 1 7–8 HP 3 — HP 3
17–18 ADAT 2 1–2 HP 4 ADAT 2 1–2 HP 4
19–20 ADAT 2 3–4 ADAT 1 1–2 ADAT 2 3–4 ADAT 1 1–2
21–22 ADAT 2 5–6 ADAT 1 3–4 — ADAT 1 3–4
23–24 ADAT 2 7–8 ADAT 1 5–6 — —
25–26 (25) Talkback
(26) —
ADAT 1 7–8 (25) Talkback
(26) —
—
27–28 ADAT 2 1–2 ADAT 2 1–2
