45
The following table is for the Pro Tools | Carbon: I/O device with this AVB configuration:
• 28x42 (44.1–192 kHz)
The following table is for the Pro Tools | Carbon: I/O device with these AVB configurations:
• 28x56 / 14x14 (44.1–192 kHz)
• 42x56 / 14x14 (44.1–192 kHz)
AVB
Channels
44.1–48 kHz 88.2–96 kHz 176.4–192 kHz
AVB In 1–28 AVB Out 1–28 AVB In 1–28 AVB Out 1–28 AVB In 1–28 AVB Out 1–28
Pro Tools | Carbon I/O Pro Tools | Carbon I/O Pro Tools | Carbon I/O
In 1–14 Out 1–14 In 1–14 Out 1–14 In 1–14 Out 1–14
In 15–28 Out 15–28 In 15–28 Out 15–28 In 15–28 Out 15–28
1–2 Mic/Line/Inst 1–2 Mon L–R Mic/Line/Inst 1–2 Mon L–R Mic/Line/Inst 1–2 Mon L–R
3–4 Mic/Line 3–4 Line 1–2 Mic/Line 3–4 Line 1–2 Mic/Line 3–4 Line 1–2
5–6 Mic/Line 5–6 Line 3–4 Mic/Line 5–6 Line 3–4 Mic/Line 5–6 Line 3–4
7–8 Mic/Line 7–8 Line 5–6 Mic/Line 7–8 Line 5–6 Mic/Line 7–8 Line 5–6
9–10 ADAT 1 1–2 Line 7–8 ADAT 1 1–2 Line 7–8 ADAT 1 1–2 Line 7–8
11–12 ADAT 1 3–4 HP 1 ADAT 1 3–4 HP 1 — HP 1
13–14 ADAT 1 5–6 HP 2 — HP 2 — HP 2
15–16 ADAT 1 7–8 HP 3 — HP 3 — HP 3
17–18 ADAT 2 1–2 HP 4 ADAT 2 1–2 HP 4 ADAT 2 1–2 HP 4
19–20 ADAT 2 3–4 ADAT 1 1–2 ADAT 2 3–4 ADAT 1 1–2 — ADAT 1 1–2
21–22 ADAT 2 5–6 ADAT 1 3–4 — ADAT 1 3–4 — —
23–24 ADAT 2 7–8 ADAT 1 5–6 — — — —
25–26 (25) Talkback
(26) —
ADAT 1 7–8 (25) Talkback
(26) —
— (25) Talkback
(26) —
—
27–28 ADAT 2 1–2 ADAT 2 1–2 ADAT 2 1–2
AVB
Channels
44.1–96 kHz 176.4–192 kHz
AVB In 1–14 AVB Out 1–14 AVB In 1–14 AVB Out 1–14
Pro Tools | Carbon I/O Pro Tools | Carbon I/O Pro Tools | Carbon I/O Pro Tools | Carbon I/O
In 1–14 Out 1–14 In 1–14 Out 1–14
1–2 Mic/Line/Inst 1–2 Mon L–R Mic/Line/Inst 1–2 Mon L–R
3–4 Mic/Line 3–4 Line 1–2 Mic/Line 3–4 Line 1–2
5–6 Mic/Line 5–6 Line 3–4 Mic/Line 5–6 Line 3–4
7–8 Mic/Line 7–8 Line 5–6 Mic/Line 7–8 Line 5–6
9–10 ADAT 1 1–2 Line 7–8 ADAT 1 1–2 Line 7–8
11–12 ADAT 1 3–4 HP 1 — HP 1
13–14 (13) ADAT 2 1
(14) Talkback
HP 2 (13) ADAT 2 1
(14) Talkback
HP 2
