Datalink (Optional)
Avidyne EX500/EX600 MFD -94- 600-00078-001 Rev 05
10.2 Two-Way Datalink
The EX500/EX600 supports an optional 2-Way Datalink transceiver
which may be:
● The MLX770 provides worldwide access via the Iridium satellite
constellation.
● The Orbcomm receiver provides North American access
(Release 4.0 and earlier). Due to variability in the Orbcomm
satellite signal, weather update rates may be unpredictable with
the ORBCOMM system.
Figure 10.2 Two-Way Datalink
The 2-Way Datalink transceiver sends your flight plan to the Avidyne
Network Operations Center (NOC), which then sends you only the
data pertinent to your flight. Two-Way Datalink can provide the
lowest-cost datalink by charging only for the data used.
Note: If you have both 2-Way Datalink and Broadcast Datalink, you
can use Avidyne’s MultiLink feature.
