5.7.4 Traffic Communications Check (Messages)
After restarting the MFD, any of the following messages may appear in the main viewing screen or the
message bar and Setup page.
Note: After completing all configuration procedures, confirm that the EX500/EX600 is configured for
the correct Traffic sensor.
Table 18: Traffic Communication Messages
Message Meaning
Traffic Sensor is Not Communicating Traffic data is not being received.
Traffic Sensor is in Stand-By (TAS/TIS) The traffic sensor has been placed in Standby mode.
Traffic Sensor is in Self-Test (TAS) The traffic sensor has been placed in Self-Test mode.
Traffic Sensor is Operating Normally Verification that Traffic data is valid.
TCAD Altitude Unavailable (TCAD) Occurs when altitude data has been lost from the TCAD sensor.
Traffic Sensor has Failed The traffic sensor has reported an internal fault, or the RS-232 ports are
not configured correctly (TCAD).
