AVM FRITZ!Box 7360 User Manual

Connecting Computers Wirelessly via WLAN
27
2. As soon as the “WLAN” LED begins flashing, enable the
WPS function on the other WLAN device, either by press-
ing a button or in the device’s user interface (depending
on the device). Activation must be started within two
minutes.
The FRITZ!Box and the WLAN device now connect with each
other automatically. The WLAN device adopts the security set-
tings of the FRITZ!Box.
As soon as the WLAN connection has been established the
computer is connected to the FRITZ!Box.
WPS with the PIN Method
If your WLAN device supports WPS, but does not have a but-
ton to start the push method nor any possibility to enable it in
its control software, use the PIN method to establish the
WLAN connection.
You can choose between two methods:
• the FRITZ!Box specifies the PIN
• the WLAN device specifies the PIN.
The FRITZ!Box Specifies the PIN
1. Open the FRITZ!Box user interface.
2. Select the “WLAN / Security” menu.
3. Go to the “WPS Quick Connection” page.
Info
Fixed Line
Internet
WLAN
Power/DSL
f
f
o
Info
I
Push for approx.
6 seconds
FRITZ!Box_7360-en.fm Seite 27 Mittwoch, 15. Februar 2012 5:21 17

AVM FRITZ!Box 7360 Specifications

General

Plug and Play	Yes
Internal memory	512 MB
RJ-11 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Bandwidth	2.4 GHz
Rack mounting	No
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Frequency range	2.4 - 2.4835 GHz
Power supply type	DC/11W
Dimensions (WxDxH)	226 x 159 x 47 mm
USB connector type	USB Type-A
WLAN data transfer rates supported	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Firewall security	IPv6
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Power supply	11 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	8 W
Product color	Red

Weight and Dimensions

Depth	159 mm
Width	226 mm
Height	47 mm
Weight	- g
