62 AMX Switch Series Installer/User Guide
Accessing the Command Line
Table 4.3 provides a list of hotkey sequences used to activate the Command Line. The default
Command Line hotkey sequence is the
NumLock key pressed and held, followed by the Minus (-)
key. You can set the following hotkey sequences from the list available on the Console tab.
To change the OSCAR interface command line sequence:
1. Press
Ctrl+Ctrl to launch the OSCAR interface.
2. Click the Console tab, then
click the down arrow button to display the Configure screen.
Figure 3.30: Configure Screen
3. Click the Cmd Line drop-down menu and select a command line.
4. To save changes, click Apply. The s
elected sequence changes from black to blue text. To exit
the OSCAR interface, click Cancel or X.
Resetting the keyboard and mouse
Should you lose keyboard and mouse connectivity, you can use the Command Line to quickly
restore default settings for the keyboard and mouse attached to the user station you are currently
logged in to.
Table 3.5: OSD Command Line Hotkey Sequences
Sequence Keystroke Description
NumLock + “-”
NumLock key, pressed and held, followed by the Minus (-) key
NumLock + “/”
NumLock key, pressed and held, followed by the Slash (/) key
NumLock + “+” NumLock key, pressed and held, followed by the Plus (+) key
NumLock + “*”
NumLock key, pressed and held, followed by the Asterisk (*) key
