Appendices 81
Humidity
10 to 90% noncondensing operating
Supported Hardware
Peripherals PS/2 keyboard and mouse, USB keyboard and mouse
Video Resolution
Standard (AMX 5111 user station):
1600 x 1200 up to 75 HZ with 100 feet of UTP from target device to user
1280 x 1024 up to 85 HZ with 500 feet of UTP from target device to user
1024 x 768 up to 85 HZ with 1000 feet of UTP from target device to user
Widescreen (A
M
X 5111 user station))::
1680 x 1050 up to 60 HZ with 100 feet of UTP from target device to user
1440 x 900 up to 75 HZ with 300 feet of UTP from target device to user
1360 x 768 up to 60 HZ with 500 feet of UTP from target device to user
848 x 480 @ 60 HZ with 100 feet of UTP from target device to user
Standard (AMX 5121 user station)):
1920 x 1440 @ 60 Hz with 100 feet of UTP from target device to user
1600 x 1200 up to 75 HZ with 200 feet of UTP from target device to user
1280 x 1024 up to 85 HZ with 1000 feet of UTP from target device to user
Widescreen (AMX 5121 user station)):
1920 x 1200 @ 60 HZ with 100 feet of UTP from target device to user
1680 x 1050 up to 60 HZ with 200 feet of UTP from target device to user
1440 x 900 up to 75 HZ with 800 feet of UTP from target device to user
1360 x 768 up to 60 HZ with 1000 feet of UTP from target device to user
Sync Types Separate horizontal and vertical; sync on green (as used on SGI and HP9000)
Safety and EMC
A
p
provals and
Markings
UL, FCC, cUL, ICES-003, CE, VCCI, C-Tick
Table 1.7: AMIQ Module Specifications
Server Ports
Number
1
Type AMIQ-PS2 module, AMIQ-USB module, AMIQ-VSN module
Connector AMIQ-PS2 module: 6-pin miniDIN, PS/2 keyboard and mouse; 15HDD male,
VGA video; 2 RJ
-45 AMX switch interconnect
AMIQ-VSN module: 8-pin miniDIN, Sun keyboard and mouse; 13W3 male,
VGA v
ideo
AMIQ-WSN module: 8-pin miniDIN, Sun keyboard and mouse; 13W3 male,
VGA v
ideo
AMIQ-USB module: USB keyboard and mouse (supports Intel, Sun,
Macintosh)
, 15HDD male, VGA video
Table 1.6: AMX 5111 and AMX 5121 User Station Specifications (Continued)
