80 AMX Switch Series Installer/User Guide
Video Resolution
Standard:
• 1920 x 1440 @ 60 Hz with 100 feet of UTP from target device to user
• 1600 x 1200 up to 75 HZ with 200 feet of UTP from target device to user
• 1280 x 1024 up to 85 HZ with 1000 feet of UTP from target device to user
Widescreen:
• 1920 x 1200 @ 60 HZ with 100 feet of UTP from target device to user
• 1680 x 1050 up to 60 HZ with 200 feet of UTP from target device to user
• 1440 x 900 up to 75 HZ with 800 feet of UTP from target device to user
• 1360 x 768 up to 60 HZ with 1000 feet of UTP from target device to user
Sync Types Separate horizontal and vertical; sync on green (as used on SGI and HP9000)
Safety and EMC
A
p
provals and
Markings
UL, FCC, cUL, ICES-003, CE, VCCI, C-Tick
Table 1.6: AMX 5111 and AMX 5121 User Station Specifications
Server Ports
Number 2
Connectors RJ-45 AMX switch interconnect
User Ports
Number PS/2: 2; VGA video: 1; USB: 2; Serial: 1
Type
PS/2, VGA video, USB, and Serial
Connectors
PS/2: 6-pin miniDIN, PS/2 keyboard and mouse; VGA video:15HDD female;
USB: Type A; Serial: DB9 male
Mechanical
H x W x D 44.5 x 279 x 292 mm 1U form factor (1.8 x 11 x 11.5 in)
Weight
2 kg (4.41 lb)
Environmental
Heat Dissipation 90 kJ
Power Consumption 25 W maximum
AC Power 100 to 240 VAC, 50/60 Hz
Temperature
0° to 40° Celsius (32° to 104° Fahrenheit) operating
-20° to 60° Celsius (-4° to 140° Fahrenheit) nonoperating
Table 1.5: AMX 5130 User Station Specifications (Continued)
AMX.book Page 80 Thursday, June 12, 2008 4:14 PM
