Appendices 83
Plug and Play DDC2B
User Ports
Number 2
Connectors
RJ-45 AMX switch interconnect
Audio (Bandwidth) 7.5 KHz
Serial (Baud Rate) 38.4 KBaud
Mechanical
H x W x D 20 x 39 x 78 mm (0.8 x 1.5 x 3.1 in)
Weight
0.13 kg (0.29 lb)
Environmental
Power Consumption 1W
DC-input voltage 6 VDC
Temperature
0° to 40° Celsius (32° to 104° Fahrenheit) operating
-20° to 60° Celsius (-4° to 140° Fahrenheit) nonoperating
Humidity
10 to 95% noncondensing operating
Safety and EMC
Approvals and
Markings
UL, FCC, cUL, ICES-003, CE, VCCI, C-Tick
Table 1.9: AMIQ-SRL Module Specifications
Server Ports
Number
1
Type DCE
Connector
9-pin D-sub female
User Ports
Number 1
Connectors
RJ-45 AMX switch interconnect
Serial Ports
Table 1.8: AMIQDM Module Specifications (Continued)
AMX.book Page 83 Thursday, June 12, 2008 4:14 PM
