84 AMX Switch Series Installer/User Guide
Type
DCE
Emulation
VT100
Baud Rate
115200, 57600, 38400, 19200, 9600, 2400, 1200, 300 bits per second
Parity
Even, Odd, None
Flow Control None, CTS/RTS or XOn/XOff
Mechanical
H x W x D 20 x 39 x 78 mm (0.8 x 1.5 x 3.1 in) with serial connector
Weight
0.13 kg (0.29 lb)
Environmental
AC-input current rating
230 mA
DC-input voltage 5 VDC
Temperature
10° to 50° Celsius (50° to 122° Fahrenheit) operating
-20° to 60° Celsius (-4° to 140° Fahrenheit) nonoperating
Humidity
10 to 95% noncondensing operating
Safety and EMC
Approvals and
Markings
UL, FCC, cUL, ICES-003, CE, VCCI, C-Tick
Table 1.9: AMIQ-SRL Module Specifications (Continued)
