20 AMX Switch Series Installer/User Guide
Figure 2.9: Connecting a User Station for Switch Redundancy
Connecting an AMIQDM Module for Dual Port Output
The AMIQDM module supports connectivity to one or two AMX switches, enabling access from
twice the number of user stations without the need to cascade switches.
Network
Server with
AMWorks Software
AMX Switch
(AMX 5000 Switch Shown)
AMX Switch
(AMX 5000 Switch Shown)
Target Server Ports
Target Server Ports
UTP Cable
UTP Cable
AMX User Station
(AMX 5130 User Station Shown)
PS/2 Mouse
and Keyboard
Ports
Serial Port
Stereo Speakers and
Microphone
Monitor
USB Keyboard and Mouse
