82 AMX Switch Series Installer/User Guide
Sync Types Separate horizontal and vertical; sync on green; composite sync
Plug and Play DDC2B
User Ports
Number 1
Connectors
RJ-45 AMX switch interconnect
Audio (Bandwidth) 7.5K Hz
Serial (Baud Rate) 38.4 KBaud
Mechanical
H x W x D 20 x 39 x 460 mm (0.8 x 1.5 x 18.1 in)
Weight
0.13 kg (0.29 lb)
Environmental
Power Consumption 650 mW
DC-input voltage 5 VDC
Temperature
10° to 50° Celsius (50° to 122° Fahrenheit) operating
-20° to 60° Celsius (-4° to 140° Fahrenheit) nonoperating
Humidity
10 to 95% noncondensing operating
Safety and EMC
Approvals and
Markings
UL, FCC, cUL, ICES-003, CE, VCCI, C-Tick
Table 1.8: AMIQDM Module Specifications
Server Ports
Number
1
Type AMIQDM-PS2 module, AMIQDM-USB module, AMIQDM-VSN module
Connector • AMIQDM-PS2 module: 6-pin miniDIN, PS/2 keyboard and mouse; 15HDD
male, VGA video; 2 RJ-4
5 AMX switch interconnect; 2 audio; serial port
• AMIQDM-USB module: USB keyboard and mouse (supports Intel, Sun,
Macintosh)
, 15HDD male, VGA video; 2 audio; serial port
• AMIQDM-VSN module: 8-pin miniDIN, Sun keyboard and mouse; 13W3 male,
VGA video; 2 RJ
-45 AMX switch interconnect; 2 audio; serial port
Sync Types Separate horizontal and vertical; sync on green; composite sync
Table 1.7: AMIQ Module Specifications (Continued)
AMX.book Page 82 Thursday, June 12, 2008 4:14 PM
