78 AMX Switch Series Installer/User Guide
Table 1.4: AMX 5030 Switch Specifications
Server Ports
Number 16
Connectors RJ-45 AMX switch interconnect
User Ports
Number 4
Connectors RJ-45 AMX switch interconnect
Network Connection
Number 1
Type Ethernet, 10BaseT, 100BaseT
Connector RJ-45
Terminal Port
Number 1
Type RS-232 serial
Connector DB9 male
Mechanical
H x W x D 43 x 432 x 351 mm 1 U form factor (1.7 x 17 x 13.8 in)
Weight 3.7 kg (8 lb)
Environmental
Heat Dissipation 270 kJ
Power Consumption 75 W maximum
AC Power 100 to 240 VAC, 50/60 Hz
Temperature
0° to 50° Celsius (32° to 122° Fahrenheit) operating
-20° to 50° Celsius (-4° to 122° Fahrenheit) nonoperating
Humidity
10 to 90% noncondensing operating
Safety and EMC
Approvals and
Markings
UL, FCC, cUL, ICES-003, CE, VCCI, C-Tick
