Chapter 2: Installation 23
Figure 2.11: Cascaded AMX Switching System, Blocking Configuration
8 AMX User Stations
(AMX 5111 User Station Shown)
UTP Cabling
4 User Paths
Target Devices
Target Devices
User Ports
AMX Switch
(8 x 32, AMX 5000 Switch Shown)
Server Ports
User Ports
Server Ports
AMX Switch
(4 x 16, AMX 5030 Switch Shown)
PRIMARY TIER
SECONDARY TIER
Non-blocking Configuration
Blocking Configuration
AMX.book Page 23 Thursday, June 12, 2008 4:14 PM
