10 AMX Switch Series Installer/User Guide
Figure 2.2 illustrates one possible switching system configuration using AMIQ and
AMIQ-SRL modules.
Figure 2.2: AMX Switching System Configuration with AMIQ and AMIQ-SRL Modules
AMX Switch (AMX 5000 Switch Shown)
AMX User Station
(AMX 5130 User Station Shown)
AMIQ-SRL
Module
Local PC
AMIQ
Module
(PS/2 Shown)
Server with
AMWorks Software
USB Keyboard
and Mouse
Serial Device
Stereo Speakers
and Microphone
Monitor
Target Devices
Serial Port
AMX.book Page 10 Thursday, June 12, 2008 4:14 PM
