Axis ME-02/N/LCD - 4-20 mA Analog Connection

18 ME-02 USER MANUAL MD004
_____________________________________________________________________________________________
External keys connection:
Scale External keys
+24V
CLR
RESTART
12
19
14
20
transoptor
5.4 4-20mA analog connection (option)
4-20mA analog out conection (0-20mA, 0-10V):
Scale External device
Attention: Rwe<510Ω
1
6
2
7
3
8
4
9
5
R
WE
+4-20mA
-4-20mA
