ME-02 USER MANUAL MD004 15

_____________________________________________________________________________________________

5.1 Meter’s connections description

ME-02 meter in stainless steel housing:

Tensometr

~230V

GND

RS232C

WE (Input)

WY (Output)

Tensometr (Weighing sensor)

GND connect with additional wire. It is recommended to use additional GND for platform also.

Internal bar to connect steering outputs witch batching devices (WY) and to external keys (WE):
