The Product Label is on all MICROSPEED PLUSDrives. The Label
printed above is a typical example. To identify the various options see
below: Product type and Identification:
ADJ is the identification of specific adjustments on the product for
specific motors. If the product is furnished Standard, the ADJ will show
the disbursed current.
ORD is AXOR's internal order number which relates to product
distribution. Always quote this number when asking for technical
assistance.
1.5 Drive Label Description (example)
General Description
Name: MCS PLUS
Model: 060-140-200
Size: 01/02- 2.5/5 -06/12 -10/20 -14/28 -20/40
Heatsink: N=Normal, B=Booster
Protection: S=Standard, T= Tropicalized
1000: Axor identification number
Feedback: T0= Tachogenerator, A0=Armature, E0=Encoder
Control mode: RD= Rifferential mode, I0= Demand current, PD=Pwm+Dir
ORDERING CODE
MCS PLUS-140-5/10-N-S-1000-T0-RD
ADJ 5/10A RA
Date 27/01/01 Ord. 365 /2001
