Service Manual
Plus
MICROSPEED
Power cable specification is recommended as follows:
1.5 square mm up to 6/12
2.5 square mm up to 10/20
The +M and -M drive outputs can be connected directly to the
motor terminals.
The minimum motor inductance value is 0.5 mH. In the case of
motors driven with armature inductance lower than 0.5 mH, it is
necessary to use a chokes connected in series with the motor.
3.11 Power Connections
Installation
