17
Service Manual
Plus
MICROSPEED
16 -LM SW (IN)
General Description
Logic input that , disable with positive rotation (CW) of
motor.(Motor limit).
Such a function is enabled, by open soldering point S10 and
connecting a positive Voltage (between +5Vdc e +24Vdc)on
said input. When the current on said input is absent, motor
rotation blockage intervenes in a counter-clockwise sense.
See Chapter 3.10
+AT (Input).
Positive continuous power supply.
+M (Output).
Motor connection +
GROUND(IN/OUT).
Ground drive
-M (Output).
Motor connection -
Negative Continuous power supply.
Common Zero Signal GND
-AT (Input).
1.8 Power Supply Inputs and Outputs
