Axor Microspeed Plus Series - 3.1 Ventilation

23
Service Manual
Plus
MICROSPEED
MicroPower Plus Power Supply (optional)
Combination table of dissipators present on Microspeed Plus.
n.a = Unavailable size with Microspeed Plus.(Available with Microspeed Case
PM1)
N = Microspeed Plus with normal radiator (See Chapter 1.5)
B = Microspeed Plus with added radiator Booster (See
Chapter 1.4)
NV = Microspeed Plus + supplementary ventilation.
BV = Microspeed Plus with added radiator Booster + supplementary
ventilation.
Installation
